Drivers
12 x 3" Wideband transducer

Frequency range
100 Hz - 16 kHz (- 10 dB)
140 Hz - 14 kHz (+/- 3 dB)

Coverage range (h x v)
80° x 20°

Impedance
12 Ω

Powerhandling (AES / program / peak)
240 W / 480 W / 960 W

Sensitivity 1 W/1 m
95,5 dB SPL

Sound pressure at (AES / program / peak)
119 dB SPL / 122 dB SPL / 125 dB SPL

Connection
2 x Neutrik NL4 IN/OUT 1+/- (4-pole looped-through)

Finish
Polyurea coating in RAL 9005

Dimensions / Weight
1.034,5 (H) × 115 (W) × 145 mm (D) / 7,4 kg
